| Part number: | PWB100A40 |
| Description: | THYRISTOR MODULE 400V 100A |
| Manufacturer | SANREX |
| Encapsulation | Tray |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "SANREX" |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Operating Temperature | -30°C ~ 150°C (TJ) |
| Structure | Bridge, 3-Phase - All SCRs |
| Current - Hold (Ih) (Max) | 70 mA |
| Current - Gate Trigger (Igt) (Max) | 150 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 3200A, 3500A |
| Number of SCRs, Diodes | 3 SCRs |
| Current - On State (It (AV)) (Max) | 100 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2 V |
| Current - On State (It (RMS)) (Max) | 157 A |
| Voltage - Off State | 400 V |
|
