| Part number: | MHBS504600KHSD |
| Description: | CAP FILM 6UF 10% 900VDC RADIAL |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 266 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Radial - 4 Leads |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | DC Link, DC Filtering; High Frequency, Switching |
| Lead Spacing | 1.083" (27.50mm) |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - DC | 900V |
| Height - Seated (Max) | 1.299" (33.00mm) |
| Capacitance | 6 µF |
| ESR (Equivalent Series Resistance) | 7 mOhms |
| Size / Dimension | 1.260" L x 0.709" W (32.00mm x 18.00mm) |
|
