| Part number: | PSB2104330KRS |
| Description: | CAP FILM 3.3UF 10% 1KVDC RADIAL |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 80 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Radial |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Lead Spacing | 2.067" (52.50mm) |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 575V |
| Voltage Rating - DC | 1000V (1kV) |
| Height - Seated (Max) | 1.969" (50.00mm) |
| Capacitance | 3.3 µF |
| ESR (Equivalent Series Resistance) | 2.8 mOhms |
| Size / Dimension | 2.264" L x 1.378" W (57.50mm x 35.00mm) |
|
