| Part number: | GSFK3420 |
| Description: | MOSFET N/P-CH 30V 0.8A SOT363 |
| Manufacturer | Good Ark Semiconductor |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Good Ark Semiconductor" |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Mounting Type | Surface Mount |
| Configuration | N and P-Channel Complementary |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 275mW (Tc) |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 800mA (Tc), 400mA (Tc) |
| Input Capacitance (Ciss) (Max) @ Vds | 146pF @ 15V |
| Rds On (Max) @ Id, Vgs | 450mOhm @ 300mA, 4.5V, 1Ohm @ 300mA, 4.5V |
| Gate Charge (Qg) (Max) @ Vgs | 5.2nC @ 4.5V, 6.2nC @ 4.5V |
| Vgs(th) (Max) @ Id | 1.2V @ 250µA |
| Supplier Device Package | SOT-363 |
|
