| Part number: | UT6JE5TCR |
| Description: | MOSFET 2P-CH 100V 1A HUML2020L8 |
| Manufacturer | ROHM Semiconductor |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "ROHM Semiconductor" |
| Package / Case | 6-PowerUDFN |
| Mounting Type | Surface Mount |
| Configuration | 2 P-Channel |
| Operating Temperature | 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| Power - Max | 2W (Ta) |
| Drain to Source Voltage (Vdss) | 100V |
| Current - Continuous Drain (Id) @ 25°C | 1A (Ta) |
| Input Capacitance (Ciss) (Max) @ Vds | 90pF @ 50V |
| Rds On (Max) @ Id, Vgs | 840mOhm @ 1A, 10V |
| Gate Charge (Qg) (Max) @ Vgs | 6.7nC @ 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Supplier Device Package | HUML2020L8 |
|
