| Part number: | TMUX4051DYYR |
| Description: | 12-V, 8:1, ONE-CHANNEL MULTIPLEX |
| Manufacturer | Texas Instruments |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Texas Instruments" |
| Package / Case | SOT-23-16 Thin, SOT-23 Variant |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C (TA) |
| On-State Resistance (Max) | 240Ohm |
| -3db Bandwidth | 430MHz |
| Supplier Device Package | 16-SOT-23-THIN |
| Voltage - Supply, Single (V+) | 5V ~ 24V |
| Voltage - Supply, Dual (V±) | ±12V |
| Charge Injection | 2pC |
| Crosstalk | -90dB @ 1MHz |
| Switch Circuit | SP8T - Open |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Channel-to-Channel Matching (ΔRon) | 2Ohm |
| Switch Time (Ton, Toff) (Max) | 110ns, 85ns (Typ) |
| Channel Capacitance (CS(off), CD(off)) | 3pF, 9pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Number of Circuits | 1 |
|
