| Part number: | VSSAF5M63HM3/I |
| Description: | 5A, 60V SLIMSMA TRENCH SKY RECT. |
| Manufacturer | Vishay |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 14000 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Vishay" |
| Package / Case | DO-221AC, SMA Flat Leads |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | 700pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 2.6A |
| Supplier Device Package | DO-221AC (SlimSMA) |
| Operating Temperature - Junction | -40°C ~ 175°C |
| Grade | Automotive |
| Voltage - DC Reverse (Vr) (Max) | 60 V |
| Voltage - Forward (Vf) (Max) @ If | 660 mV @ 5 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 60 V |
| Qualification | AEC-Q101 |
|
