| Part number: | DG441LDQ-E3 |
| Description: | IC SW SPST-NCX4 30OHM 16TSSOP |
| Manufacturer | Vishay / Siliconix |
| Encapsulation | Bulk |
| Quantity | 360 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Vishay / Siliconix" |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 30Ohm |
| -3db Bandwidth | 280MHz |
| Supplier Device Package | 16-TSSOP |
| Voltage - Supply, Single (V+) | 2.7V ~ 12V |
| Voltage - Supply, Dual (V±) | ±3V ~ 6V |
| Charge Injection | 5pC |
| Crosstalk | -95dB @ 1MHz |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ΔRon) | 100mOhm |
| Switch Time (Ton, Toff) (Max) | 60ns, 35ns |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 6pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Number of Circuits | 4 |
|
