| Part number: | 124D |
| Description: | XFMR 7KCT / 15.8KCT CHAS MNT |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 2.810" L x 1.460" W (71.37mm x 37.08mm) |
| Mounting Type | Chassis Mount |
| Termination Style | Wire Leads |
| Transformer Type | Tube Driver and Speaker Matching |
| Turns Ratio - Primary:Secondary | 1:1.49 |
| Frequency Range | 150Hz ~ 15kHz |
| Voltage - Isolation | 500Vrms |
| Height - Seated (Max) | 1.680" (42.67mm) |
| Impedance - Primary (Ohms) | 7kCT |
| Impedance - Secondary (Ohms) | 15.8kCT |
| DC Resistance (DCR) - Primary | 218Ohm, 236Ohm |
| DC Resistance (DCR) - Secondary | 297Ohm, 394Ohm |
| Frequency Response | ±1dB |
| Power Level | 5W |
|
