| Part number: | 145C |
| Description: | AUDIO XFMR 50K / 1.5KCT CHAS MNT |
| Manufacturer | Hammond Manufacturing |
| Encapsulation | Bulk |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Hammond Manufacturing" |
| Size / Dimension | 1.630" L x 0.880" W (41.40mm x 22.35mm) |
| Mounting Type | Chassis Mount |
| Termination Style | Wire Leads |
| Transformer Type | Economical Open Type |
| Frequency Range | 150Hz ~ 15kHz |
| Height - Seated (Max) | 0.810" (20.57mm) |
| Impedance - Primary (Ohms) | 50k |
| Impedance - Secondary (Ohms) | 1.5kCT |
| DC Resistance (DCR) - Primary | 2.4kOhm |
| DC Resistance (DCR) - Secondary | 52Ohm |
| Frequency Response | ±1dB |
| Power Level | 50mW |
|
