| Part number: | SI83404AAA-IF |
| Description: | DGTL ISOL 1500VRMS 4CH SPI 32DFN |
| Manufacturer | Skyworks Solutions, Inc. |
| Encapsulation | Tray |
| Quantity | 260 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Skyworks Solutions, Inc." |
| Package / Case | 32-VFDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Type | SPI |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 2.25V ~ 5.5V |
| Technology | Capacitive Coupling |
| Voltage - Isolation | 1500Vrms |
| Inputs - Side 1/Side 2 | 4/0 |
| Supplier Device Package | 32-DFN (9x9) |
| Rise / Fall Time (Typ) | 3µs, 3µs |
| Common Mode Transient Immunity (Min) | 100kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 2.3µs, 2.9µs (Typ) |
| Isolated Power | No |
| Channel Type | Unidirectional |
| Pulse Width Distortion (Max) | 10µs (Min) |
| Number of Channels | 4 |
|
