| Part number: | BXRV-TR-2765G-40A0-A-23 |
| Description: | LED COB VESTA WHITE SQUARE 4600K |
| Manufacturer | Bridgelux, Inc. |
| Encapsulation | Tube |
| Quantity | 20 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Bridgelux, Inc." |
| Color | White, Warm / White, Cool |
| Size / Dimension | 24.00mm L x 24.00mm W |
| Type | Chip On Board (COB) |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 35.3V |
| Height | 1.65mm |
| Current - Test | 900mA |
| Viewing Angle | 130° |
| Lens Type | Flat |
| Current - Max | 1.4A |
| Lumens/Watt @ Current - Test | 127 lm/W |
| CCT (K) | 4600K (2700K ~ 6500K) 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 92 |
| Light Emitting Surface (LES) | 19.70mm Dia |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 4026lm (Typ) |
|
