| Part number: | ALQ3F18 |
| Description: | RELAY GEN PURPOSE SPST 10A 18V |
| Manufacturer | Panasonic Electric Works |
| Encapsulation | Box |
| Quantity | 100 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Panasonic Electric Works" |
| Mounting Type | Through Hole |
| Coil Voltage | 18VDC |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Approval Agency | CQC, cURuus, VDE |
| Relay Type | General Purpose |
| Coil Current | 11.1 mA |
| Coil Type | Non Latching |
| Contact Material | Silver Nickel (AgNi) |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 5 A |
| Switching Voltage | 250VAC, 30VDC - Max |
| Must Release Voltage | 0.9 VDC |
| Must Operate Voltage | 13.5 VDC |
| Operate Time | 20 ms |
| Release Time | 20 ms |
| Coil Resistance | 1.62 kOhms |
| Coil Insulation | Class F |
| Load - Max Switching | 1250VA, 150W |
|
