| Part number: | ST-7-56 |
| Description: | PWR XFMR LAMINATED 36VA TH |
| Manufacturer | Signal Transformer |
| Encapsulation | Bulk |
| Quantity | 20 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Signal Transformer" |
| Size / Dimension | 66.70mm L x 55.50mm W |
| Mounting Type | Through Hole |
| Type | Laminated Core |
| Weight | 1.1 lbs (499 g) |
| Termination Style | PC Pin |
| Primary Winding(s) | Single |
| Secondary Winding(s) | Dual |
| Power - Max | 36VA |
| Voltage - Isolation | 2500Vrms |
| Current - Output (Max) | Parallel 1.3A, Series 650mA |
| Voltage - Primary | 115V |
| Height - Seated (Max) | 40.40mm |
| Voltage - Secondary (Full Load) | Parallel 28V, Series 56V |
| Center Tap | No |
|
