| Part number: | BTD24-12W45S |
| Description: | DC DC CONVERTER +/-12V 11W |
| Manufacturer | Bellnix Co., LTD. |
| Encapsulation | Bulk |
| Quantity | 30 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Bellnix Co., LTD." |
| Features | Adjustable Output, Remote On/Off |
| Package / Case | 8-SMD Module, 7 Leads |
| Size / Dimension | 1.41" L x 0.89" W x 0.33" H (35.9mm x 22.6mm x 8.5mm) |
| Mounting Type | Surface Mount |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Efficiency | 86% |
| Current - Output (Max) | 450mA, 450mA |
| Voltage - Input (Min) | 18V |
| Voltage - Output 1 | 12V |
| Voltage - Output 2 | -12V |
| Power (Watts) | 11 W |
| Number of Outputs | 2 |
| Voltage - Isolation | 500 V |
|
