| Part number: | MAL225752331E3 |
| Description: | CAP ALUM 330UF 20% 200V SNAP |
| Manufacturer | Vishay BC Components |
| Encapsulation | Box |
| Quantity | 100 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Vishay BC Components" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - Snap-In |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | 0.394" (10.00mm) |
| ESR (Equivalent Series Resistance) | 440mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Capacitance | 330 µF |
| Voltage - Rated | 200 V |
| Impedance | 310 mOhms |
| Ripple Current @ Low Frequency | 1.51 A @ 100 Hz |
| Ripple Current @ High Frequency | 2.114 A @ 10 kHz |
|
