| Part number: | MAL225757151E3 |
| Description: | CAP ALUM 150UF 20% 450V SNAP |
| Manufacturer | Vishay BC Components |
| Encapsulation | Box |
| Quantity | 100 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Vishay BC Components" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - Snap-In |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | General Purpose |
| Lead Spacing | 0.394" (10.00mm) |
| ESR (Equivalent Series Resistance) | 1.19Ohm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Height - Seated (Max) | 1.654" (42.00mm) |
| Capacitance | 150 µF |
| Voltage - Rated | 450 V |
| Impedance | 980 mOhms |
| Ripple Current @ Low Frequency | 1.2 A @ 100 Hz |
| Ripple Current @ High Frequency | 1.68 A @ 10 kHz |
|
