| Part number: | ELC-18E182 |
| Description: | FIXED IND 1.8MH 800MA 570MOHM TH |
| Manufacturer | Panasonic Electronic Components |
| Encapsulation | Bulk |
| Quantity | 500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Panasonic Electronic Components" |
| Tolerance | ±10% |
| Package / Case | Radial, Vertical Cylinder (Open) |
| Size / Dimension | 0.748" Dia (19.00mm) |
| Mounting Type | Through Hole |
| Shielding | Shielded |
| Type | Drum Core, Wirewound |
| DC Resistance (DCR) | 570mOhm |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 10 kHz |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Inductance | 1.8 mH |
| Current Rating (Amps) | 800 mA |
|
