| Part number: | VX7803-1000R |
| Description: | DC DC CONVERTER 3.3V 3.3W |
| Manufacturer | CUI Inc |
| Encapsulation | Tube |
| Quantity | 44 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "CUI Inc" |
| Package / Case | 3-SIP Module |
| Size / Dimension | 0.69" L x 0.45" W x 0.35" H (17.5mm x 11.5mm x 9.0mm) |
| Mounting Type | Through Hole, Right Angle |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Approval Agency | CB Scheme, EN, IEC, UL |
| Efficiency | 90% |
| Current - Output (Max) | 1A |
| Voltage - Input (Min) | 6V |
| Voltage - Output 1 | 3.3V |
| Power (Watts) | 3.3 W |
| Number of Outputs | 1 |
| Standard Number | 55024; 55032 Class A; 60950-1 |
|
