| Part number: | PRMCE1-S5-S3-S |
| Description: | DC DC CONVERTER 3.3V 825MW |
| Manufacturer | CUI Inc |
| Encapsulation | Tube |
| Quantity | 25 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "CUI Inc" |
| Package / Case | 7-SIP Module, 4 Leads |
| Size / Dimension | 0.77" L x 0.24" W x 0.40" H (19.7mm x 6.0mm x 10.2mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 5.25V |
| Approval Agency | EN |
| Efficiency | 67% |
| Current - Output (Max) | 250mA |
| Voltage - Input (Min) | 4.75V |
| Voltage - Output 1 | 3.3V |
| Power (Watts) | 825 mW |
| Number of Outputs | 1 |
| Voltage - Isolation | 3 kV |
| Standard Number | 55024; 55032 Class A |
|
