| Part number: | M-22S10 1K |
| Description: | POT 1K OHM 2W WIREWOUND LINEAR |
| Manufacturer | Nidec Copal Electronics (Nidec Components) |
| Encapsulation | Bulk |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nidec Copal Electronics (Nidec Components)" |
| Resistance (Ohms) | 1k |
| Power (Watts) | 2W |
| Tolerance | ±0.2% |
| Temperature Coefficient | ±50ppm/°C |
| Adjustment Type | User Defined |
| Mounting Type | Panel Mount |
| Termination Style | Solder Lug |
| Bushing Thread | M9 x 0.75 |
| Actuator Length | 0.906" (23.00mm) |
| Actuator Type | Slotted |
| Built in Switch | None |
| Actuator Diameter | 0.236" (6.00mm) |
| Resistive Material | Wirewound |
| Taper | Linear |
| Rotation | 3600° |
| Size - Body | Round - 0.866" Dia (22.00mm) |
| Number of Gangs | 1 |
| Number of Turns | 10 |
|
