| Part number: | AZSR165-1A-24DL |
| Description: | RELAY EV CHG SOLAR SPST 80A 24V |
| Manufacturer | American Zettler |
| Encapsulation | Tube |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "American Zettler" |
| Mounting Type | Through Hole |
| Coil Voltage | 24VDC |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | PC Pin |
| Approval Agency | TUV, UL |
| Relay Type | EV Charging, Solar |
| Coil Current | 92.3 mA |
| Coil Type | Non Latching |
| Contact Material | Silver Nickel (AgNi) |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 80 A |
| Switching Voltage | 690VAC - Max |
| Must Release Voltage | 1.2 VDC |
| Must Operate Voltage | 18 VDC |
| Operate Time | 40 ms |
| Release Time | 20 ms |
| Coil Insulation | Class F |
| Load - Max Switching | 55200VA |
|
