| Part number: | SMA281LB G/W |
| Description: | 0.28" SGL SMD DISPLAY - BLUE |
| Manufacturer | American Opto Plus LED Corp. |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "American Opto Plus LED Corp." |
| Package / Case | 10-SMD, No Lead |
| Color | Blue |
| Display Type | 7-Segment |
| Size / Dimension | 0.394" H x 0.295" W x 0.159" D (10.00mm x 7.50mm x 4.05mm) |
| Number of Characters | 1 |
| Millicandela Rating | 20mcd |
| Common Pin | Common Anode |
| Digit/Alpha Size | 0.28" (7.00mm) |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Current - Test | 20mA |
| Wavelength - Peak | 470nm |
| Power Dissipation (Max) | 120mW |
|
