| Part number: | AM1P-2407DZ |
| Description: | DC DC CONVERTER +/-7.2V 1W |
| Manufacturer | Aimtec |
| Encapsulation | Tube |
| Quantity | 40 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Aimtec" |
| Package / Case | 8-DIP Module |
| Size / Dimension | 0.50" L x 0.40" W x 0.27" H (12.7mm x 10.2mm x 6.9mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 85°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 26.4V |
| Approval Agency | CE |
| Efficiency | 76% |
| Current - Output (Max) | 69mA, 69mA |
| Voltage - Input (Min) | 21.6V |
| Voltage - Output 1 | -7.2 ~ 7.2V |
| Voltage - Output 2 | -7.2V |
| Power (Watts) | 1 W |
| Number of Outputs | 2 |
| Voltage - Isolation | 1 kV |
|
