| Part number: | AM3DG-241508DH30-NZ |
| Description: | DC DC CONVERTER 15V -8V 3W |
| Manufacturer | Aimtec |
| Encapsulation | Tube |
| Quantity | 25 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Aimtec" |
| Package / Case | 7-SIP Module |
| Size / Dimension | 0.77" L x 0.39" W x 0.49" H (19.5mm x 9.8mm x 12.5mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 105°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 25.2V |
| Approval Agency | cULus, cURus |
| Efficiency | 81% |
| Current - Output (Max) | 120mA, 120mA |
| Voltage - Input (Min) | 22.8V |
| Voltage - Output 1 | -8 ~ 15V |
| Voltage - Output 2 | -8V |
| Power (Watts) | 3 W |
| Number of Outputs | 2 |
| Voltage - Isolation | 3 kV |
|
