| Part number: | AMSR1-2412Z |
| Description: | DC DC CONVERTER 12V 12W |
| Manufacturer | Aimtec |
| Encapsulation | Tube |
| Quantity | 40 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Aimtec" |
| Package / Case | 3-SIP Module |
| Size / Dimension | 0.46" L x 0.29" W x 0.40" H (11.7mm x 7.5mm x 10.2mm) |
| Mounting Type | Through Hole |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -40°C ~ 60°C (With Derating) |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Efficiency | 93% |
| Current - Output (Max) | 1A |
| Voltage - Input (Min) | 15V |
| Voltage - Output 1 | 12V |
| Power (Watts) | 12 W |
| Number of Outputs | 1 |
|
