| Part number: | AM1D-2424DH40Z |
| Description: | DC DC CONVERTER +/-24V 1W |
| Manufacturer | Aimtec |
| Encapsulation | Tube |
| Quantity | 20 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Aimtec" |
| Package / Case | 7-SIP Module |
| Size / Dimension | 0.76" L x 0.24" W x 0.39" H (19.5mm x 6.0mm x 10.0mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 85°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 26.4V |
| Approval Agency | CE, cULus, cURus |
| Efficiency | 82% |
| Current - Output (Max) | 21mA, 21mA |
| Voltage - Input (Min) | 21.6V |
| Voltage - Output 1 | -24 ~ 24V |
| Voltage - Output 2 | -24V |
| Power (Watts) | 1 W |
| Number of Outputs | 2 |
| Voltage - Isolation | 4 kV |
|
