| Part number: | AMSR2-7809JZ |
| Description: | DC DC CONVERTER 9V 18W |
| Manufacturer | Aimtec |
| Encapsulation | Tube |
| Quantity | 44 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Aimtec" |
| Package / Case | 3-SIP Module |
| Size / Dimension | 0.45" L x 0.35" W x 0.69" H (11.5mm x 8.9mm x 17.5mm) |
| Mounting Type | Through Hole |
| Type | Non-Isolated PoL Module |
| Operating Temperature | -40°C ~ 85°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Efficiency | 90% |
| Current - Output (Max) | 2A |
| Voltage - Input (Min) | 13V |
| Voltage - Output 1 | 9V |
| Power (Watts) | 18 W |
| Number of Outputs | 1 |
|
