| Part number: | AME20-12SBJZ |
| Description: | AC/DC CONVERTER 12V 20W |
| Manufacturer | Aimtec |
| Encapsulation | Box |
| Quantity | 20 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Aimtec" |
| Package / Case | 5-DIP Module, 4 Leads |
| Size / Dimension | 2.76" L x 1.89" W x 1.18" H (70.0mm x 48.0mm x 30.0mm) |
| Mounting Type | Through Hole |
| Voltage - Input | 90 ~ 528 VAC, 100 ~ 745 VDC |
| Type | Enclosed |
| Weight | 0.353 lb (160.00 g) |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Efficiency | 82% |
| Current - Output (Max) | 1.66A |
| Load Regulation | ±1% |
| Line Regulation | ±0.5% |
| Voltage - Output 1 | 12V |
| Power (Watts) | 20 W |
| Number of Outputs | 1 |
|
