| Part number: | PMXB65ENE,147 |
| Description: | NOW NEXPERIA PMXB65ENE - SMALL S |
| Manufacturer | NXP Semiconductors |
| Encapsulation | Bulk |
| Quantity | 1402 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "NXP Semiconductors" |
| Package / Case | 3-XDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 3.2A (Ta) |
| Rds On (Max) @ Id, Vgs | 67mOhm @ 3.2A, 10V |
| Power Dissipation (Max) | 400mW (Ta), 8.33W (Tc) |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Supplier Device Package | DFN1010D-3 |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 30 V |
| Gate Charge (Qg) (Max) @ Vgs | 11 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 295 pF @ 15 V |
|
