| Part number: | EL7242CN |
| Description: | AND GATE BASED MOSFET DRIVER, 2A |
| Manufacturer | Elantec |
| Encapsulation | Bulk |
| Quantity | 116 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Elantec" |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Supply | 4.5V ~ 16V |
| Input Type | Inverting, Non-Inverting |
| Supplier Device Package | 8-PDIP |
| Rise / Fall Time (Typ) | 10ns, 10ns |
| Channel Type | Independent |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel, P-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 2A, 2A |
| DigiKey Programmable | Not Verified |
|
