| Part number: | MKP1848615084P4 |
| Description: | MKP 15UF 5% 800VDC RADIAL PITCH |
| Manufacturer | Vishay BC Components |
| Encapsulation | Bulk |
| Quantity | 91 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Vishay BC Components" |
| Tolerance | ±5% |
| Features | Low ESR |
| Package / Case | Radial - 4 Leads |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 105°C |
| Applications | Automotive; DC Link, DC Filtering |
| Lead Spacing | 1.476" (37.50mm) |
| Termination | PC Pins |
| Ratings | AEC-Q200 |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - DC | 800V |
| Height - Seated (Max) | 1.535" (39.00mm) |
| Capacitance | 15 µF |
| ESR (Equivalent Series Resistance) | 7.5 mOhms |
| Size / Dimension | 1.693" L x 0.846" W (43.00mm x 21.50mm) |
|
