| Part number: | LMCI0201-1N8ST |
| Description: | FIXED IND 1.8NH 380MA 150MOHM SM |
| Manufacturer | Venkel LTD |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 15000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Venkel LTD" |
| Tolerance | ±0.3nH |
| Package / Case | 0201 (0603 Metric) |
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Multilayer |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 150mOhm |
| Q @ Freq | 13 @ 500MHz |
| Frequency - Self Resonant | 10GHz |
| Material - Core | Ceramic |
| Inductance Frequency - Test | 100 MHz |
| Supplier Device Package | 0201 |
| Height - Seated (Max) | 0.013" (0.33mm) |
| Inductance | 1.8 nH |
| Current Rating (Amps) | 380 mA |
|
