| Part number: | BC557BBK |
| Description: | BJT TO92BK 45V PNP 0.5W 150C |
| Manufacturer | Diotec Semiconductor |
| Encapsulation | Box |
| Quantity | 5000 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Diotec Semiconductor" |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Mounting Type | Through Hole |
| Transistor Type | PNP |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 650mV @ 5mA, 100mA |
| Current - Collector Cutoff (Max) | 15nA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 200 @ 2mA, 5V |
| Frequency - Transition | 150MHz |
| Supplier Device Package | TO-92 |
| Current - Collector (Ic) (Max) | 100 mA |
| Voltage - Collector Emitter Breakdown (Max) | 45 V |
| Power - Max | 500 mW |
|
