| Part number: | FED60-24S15W |
| Description: | DC DC CONVERTER 15V 60W |
| Manufacturer | P-DUKE Technology |
| Encapsulation | Tube |
| Quantity | 10 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "P-DUKE Technology" |
| Features | Adjustable Output, Remote On/Off |
| Package / Case | 6-DIP Module |
| Size / Dimension | 2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 105°C (With Derating) |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 36V |
| Approval Agency | CB, CE, cURus |
| Efficiency | 92% |
| Current - Output (Max) | 4A |
| Voltage - Input (Min) | 9V |
| Voltage - Output 1 | 15V |
| Control Features | Enable, Active High |
| Power (Watts) | 60 W |
| Number of Outputs | 1 |
| Voltage - Isolation | 1.6 kV |
|
