| Part number: | Z1SMA6.8 |
| Description: | ZENERDIODE,SMA,6.8V,1W,5% |
| Manufacturer | Diotec Semiconductor |
| Encapsulation | Strip |
| Quantity | 30 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Diotec Semiconductor" |
| Tolerance | ±5% |
| Package / Case | DO-214AC, SMA |
| Mounting Type | Surface Mount |
| Operating Temperature | -50°C ~ 150°C (TJ) |
| Voltage - Zener (Nom) (Vz) | 6.8 V |
| Impedance (Max) (Zzt) | 4.5 Ohms |
| Supplier Device Package | DO-214AC (SMA) |
| Power - Max | 1 W |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 200 mA |
| Current - Reverse Leakage @ Vr | 1 µA @ 2 V |
|
