| Part number: | PHC1853330KJ |
| Description: | CAP FILM 0.33UF 10% 850VDC AXIAL |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 300 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Axial |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | High Frequency, Switching |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 500V |
| Voltage Rating - DC | 850V |
| Capacitance | 0.33 µF |
| ESR (Equivalent Series Resistance) | 6.6 mOhms |
| Size / Dimension | 0.551" Dia x 1.260" L (14.00mm x 32.00mm) |
|
