| Part number: | IHLP1212BZEV1R2M5A |
| Description: | FIXED IND 1.2UH 4.78A 38.99MOHM |
| Manufacturer | Vishay / Dale |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 4000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Vishay / Dale" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.140" L x 0.130" W (3.56mm x 3.30mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Molded |
| Operating Temperature | -55°C ~ 155°C |
| DC Resistance (DCR) | 38.99mOhm Max |
| Frequency - Self Resonant | 67MHz |
| Ratings | AEC-Q200 |
| Current - Saturation (Isat) | 2.97A |
| Inductance Frequency - Test | 100 kHz |
| Height - Seated (Max) | 0.079" (2.00mm) |
| Inductance | 1.2 µH |
| Current Rating (Amps) | 4.78 A |
|
