| Part number: | 225K100RA4-FA |
| Description: | CAPACITOR MLP 2.2UF 100V RADIAL |
| Manufacturer | Quantic Paktron |
| Encapsulation | Bulk |
| Quantity | 1000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Quantic Paktron" |
| Tolerance | ±10% |
| Features | Low ESR, High Temperature |
| Package / Case | Radial |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C |
| Applications | EMI, RFI Suppression; High Pulse, DV/DT |
| Lead Spacing | 0.394" (10.00mm) |
| Termination | PC Pins |
| Dielectric Material | Polyester, Metallized |
| Voltage Rating - AC | 80V |
| Voltage Rating - DC | 100V |
| Height - Seated (Max) | 0.283" (7.20mm) |
| Capacitance | 2.2 µF |
| ESR (Equivalent Series Resistance) | 6 mOhms |
| Size / Dimension | 0.449" L x 0.205" W (11.40mm x 5.20mm) |
|
