| Part number: | MWSD1005C24NJTM81 |
| Description: | FIXED IND 24NH 770MA 212MOHM SMD |
| Manufacturer | Sunlord (Shenzhen Sunlord Electronics) |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 10000 |
| RoHS |
| TYPE | DESCRIPTION |
| Mfr | "Sunlord (Shenzhen Sunlord Electronics)" |
| Tolerance | ±5% |
| Package / Case | 0402 (1005 Metric) |
| Size / Dimension | 0.043" L x 0.021" W (1.10mm x 0.53mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Type | Drum Core, Wirewound |
| Operating Temperature | -40°C ~ 125°C |
| DC Resistance (DCR) | 212mOhm Max |
| Q @ Freq | 31 @ 250MHz |
| Frequency - Self Resonant | 4GHz |
| Material - Core | Ceramic |
| Inductance Frequency - Test | 100 MHz |
| Supplier Device Package | 0402 |
| Height - Seated (Max) | 0.028" (0.70mm) |
| Inductance | 24 nH |
| Current Rating (Amps) | 770 mA |
|
