| Part number: | AEH0810470M050R |
| Description: | CAP ALUM 47UF 20% 50V SMD |
| Manufacturer | KYOCERA AVX |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 550 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "KYOCERA AVX" |
| Tolerance | ±20% |
| Package / Case | Radial, Can - SMD |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Polarization | Polar |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 125°C |
| Applications | General Purpose |
| Lifetime @ Temp. | 2000 Hrs @ 125°C |
| Surface Mount Land Size | 0.327" L x 0.327" W (8.30mm x 8.30mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Capacitance | 47 µF |
| Voltage - Rated | 50 V |
| Ripple Current @ Low Frequency | 64 mA @ 120 Hz |
| Ripple Current @ High Frequency | 160 mA @ 100 kHz |
|
