| Part number: | 2450AD18A6050001E |
| Description: | ANT2.45 / 6.05 GHZ BT/WIFI |
| Manufacturer | Johanson Technology |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 3000 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Johanson Technology" |
| Mounting Type | Surface Mount |
| Frequency Range | 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.85GHz, 5.85GHz ~ 7.2GHz |
| Applications | Bluetooth, Wi-Fi6E |
| Gain | 2dBi, 1.5dBi, 2.7dBi |
| Termination | Solder |
| Number of Bands | 3 |
| Antenna Type | Chip |
| Height (Max) | 0.024" (0.60mm) |
| Return Loss | 6dB, 5dB, 5dB |
| Frequency Group | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) |
| Frequency (Center/Band) | 2.45GHz, 5.375GHz, 6.525GHz |
| RF Family/Standard | Bluetooth, WiFi |
| Power - Max | 3 W |
|
