| Part number: | PC0504-331M-RC |
| Description: | 330UH 20% POWER CHIP INDUCTOR |
| Manufacturer | Allied Components International |
| Encapsulation | Tape & Reel (TR) |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Allied Components International" |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.228" L x 0.205" W (5.80mm x 5.20mm) |
| Mounting Type | Surface Mount |
| Shielding | Unshielded |
| Type | Wirewound |
| Operating Temperature | -55°C ~ 125°C |
| DC Resistance (DCR) | 1.7Ohm Max |
| Inductance Frequency - Test | 100 kHz |
| Height - Seated (Max) | 0.189" (4.80mm) |
| Inductance | 330 µH |
| Current Rating (Amps) | 280 mA |
|
