| Part number: | ANT-19078EB56 |
| Description: | RF ANT, CABLE 1:4G/3G/2GCABLE 2: |
| Manufacturer | Adam Tech |
| Encapsulation | Bag |
| Quantity | 1 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Adam Tech" |
| Features | Cable - 3m, Filter |
| Mounting Type | Magnetic |
| Frequency Range | 698MHz ~ 960MHz, 1.598GHz ~ 1.61GHz, 1.71GHz ~ 2.17GHz, 2.3GHz ~ 2.69GHz |
| Applications | 2G, 3G, 4G, Galileo, GLONASS, GPS |
| Gain | -0.5dBi, 2.5dBi, 0.4dBi, 0.3dBi, 0.9dBi, 0.4dBi, 3dBi, 0.6dBi, 3.2dBi |
| Number of Bands | 5 |
| VSWR | 2, 3 |
| Antenna Type | Module |
| Height (Max) | 0.564" (14.32mm) |
| Return Loss | -6dB, -15dB |
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 829MHz, 1.575GHz, 1.602GHz, 1.94GHz, 2.495GHz |
| RF Family/Standard | Cellular, Navigation |
| Power - Max | 5 W |
|
