| Part number: | MCO500-14IO1 |
| Description: | MOD THYRISTOR SGL 1400V Y1-CU |
| Manufacturer | Littelfuse / IXYS RF |
| Encapsulation | Box |
| Quantity | 2 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Littelfuse / IXYS RF" |
| Package / Case | Y1-CU |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 140°C (TJ) |
| Structure | Single |
| Current - Hold (Ih) (Max) | 300 mA |
| Current - Gate Trigger (Igt) (Max) | 300 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 17000A, 16000A |
| Number of SCRs, Diodes | 1 SCR |
| Current - On State (It (AV)) (Max) | 560 A |
| Voltage - Gate Trigger (Vgt) (Max) | 2 V |
| Current - On State (It (RMS)) (Max) | 880 A |
| Voltage - Off State | 1.4 kV |
|
