| Part number: | MABA023680KGS |
| Description: | CAP FILM 0.68UF 10% 600VDC RAD |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 500 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Radial |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 100°C |
| Applications | Motor Run |
| Lead Spacing | 0.886" (22.50mm) |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 320V |
| Voltage Rating - DC | 600V |
| Height - Seated (Max) | 0.728" (18.50mm) |
| Capacitance | 0.68 µF |
| Size / Dimension | 1.043" L x 0.394" W (26.50mm x 10.00mm) |
|
