| Part number: | PPB2162220KGL |
| Description: | CAP FILM 0.022UF 10% 1.6KVDC RAD |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 650 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Radial |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 105°C |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Lead Spacing | 0.886" (22.50mm) |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 650V |
| Voltage Rating - DC | 1600V (1.6kV) |
| Height - Seated (Max) | 0.669" (17.00mm) |
| Capacitance | 0.022 µF |
| Size / Dimension | 1.043" L x 0.335" W (26.50mm x 8.50mm) |
|
