| Part number: | PWS2201680KG |
| Description: | CAP FILM 6800PF 10% 2KVDC AXIAL |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 600 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Axial |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 105°C |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 500V |
| Voltage Rating - DC | 2000V (2kV) |
| Capacitance | 6800 pF |
| Size / Dimension | 0.394" Dia x 1.063" L (10.00mm x 27.00mm) |
|
