| Part number: | PPA2103100KG |
| Description: | CAP FILM 0.1UF 10% 1KVDC AXIAL |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 600 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Axial |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - AC | 525V |
| Voltage Rating - DC | 1000V (1kV) |
| Capacitance | 0.1 µF |
| ESR (Equivalent Series Resistance) | 10.2 mOhms |
| Size / Dimension | 0.492" Dia x 1.063" L (12.50mm x 27.00mm) |
|
