| Part number: | MHBS405150KJS |
| Description: | CAP FILM 15UF 10% 700VDC RADIAL |
| Manufacturer | Nichicon |
| Encapsulation | Bulk |
| Quantity | 160 |
| RoHS | 1 |
| TYPE | DESCRIPTION |
| Mfr | "Nichicon" |
| Tolerance | ±10% |
| Package / Case | Radial |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C ~ 85°C |
| Applications | DC Link, DC Filtering; High Frequency, Switching |
| Lead Spacing | 1.476" (37.50mm) |
| Termination | PC Pins |
| Dielectric Material | Polypropylene (PP), Metallized |
| Voltage Rating - DC | 700V |
| Height - Seated (Max) | 1.319" (33.50mm) |
| Capacitance | 15 µF |
| ESR (Equivalent Series Resistance) | 5.5 mOhms |
| Size / Dimension | 1.673" L x 0.866" W (42.50mm x 22.00mm) |
|
